Detailed introduction
AT6101 series handheld multifunctional gamma spectrometer
Product introduction
l handheldmultifunctionGamma spectrometer, inspects, tracks, identifies radionuclides, and determines the environmental equivalent dose rate
l AT6101 and AT6101B can correct the measured environmental equivalent dose rate
l Can connect external smart trackers
l Search, track and identify radionuclides, and can identify dozens of nuclides
l Spectrometer smart probe with computer interface
l Valid search patterns
l LCD 128x64 backlight displays spectral data
l Can be collected300 spectra
l Sealed in water, dimensions121x477 mm
l The instrument has a built-in clock and calendar, which are powered by a lithium battery independent of the instrument power supply.
l Applied to environmental measurement, radioactive waste control, radioactive and fissile material accidents, nuclear energy medicine, emergency incident investigation
Product features
l Gamma radioactive source survey, tracking and activity assessment
l Intelligent tracking unit
l Built-in automatic continuous stabilizing diodeLED
l Digital temperature compensation of measuring path
l Audible and visual alarms for isotopes found and threshold exceeded
l 128x64 LCD display with backlight
l recordable storage500 spectra
l Wide operating temperature range under radiation field conditions
l computer interfacear
l Measure Energy distribution of gamma radiation, dose equivalent rate of ambient gamma radiation, alpha and beta radiation flux densities.
l The spectrometer smart probe has a computer interface.
l Valid search patterns.
l by conversion"Spectral dose" is used to realize the measurement of dose rate by the spectrometer.
l host (PU) built-in G-M tube, which can expand the dose rate measurement range.
l Measurement of dose rate and flow density with automatic background subtraction.
l Continuously automaticLED stable spectrum energy scale, with KCl for periodic calibration.
l Temperature compensation of the measuring path is carried out via an integrated temperature sensor.
l search identificationDuring gamma radiation nuclide process, the dose rate and flow density exceed the limit, in order to provide visual and audible alarms.
Technical parameters
tracker | AT6101: Flashing NaI(Tl) 40x40 mm, G-M tube |
Gamma radiation energy range | 50-3000 keV |
internal nonlinearity | no more than 1% |
662keV γ relative energy resolution | 7.0 - 7.5% |
number of channels | 512 |
Maximum input load | 54 × 10-1 s |
continuous operation time | AC, 220V: no more than 24 hours |
continuous24-hour operational instability | no greater than1 % |
environmental equivalenceGamma radiation dose rate measurement range | AT6101：0.03 mSv/h - 100 mSv/h |
Internal dose rate measurement error | no greater than±15% |
Operating temperature range | -20 ¸ +50 °C |
Operating mode setting time | no greater than10 min |
protection level | IP65 |
weight | tracker unit(AT6101)：1.2 kg |
Size | tracker unit (AT6101)：60X320 mm |
